Pressure transmitters Safir 2xxx Ns have passed all the necessary compliance tests and require the industry standards of the nuclear power industry of Ukraine, and also meet the qualification requirements of class 1E according to the IEEE Std 323-2003 standard.
Differential pressure transmitters Safir 2xxx Ns for flow measurement use three types of sensitive elements depending on the measured differential pressure:
– lever type (structure of silicon on sapphire) for low pressures,
– diaphragm type (structure of silicon on sapphire) for high pressures (over 1.6 MPa).
